Product Description
Quartz glass has extremely high softening temperature, low coefficient of intestinal expansion, good thermal stability, high mechanical strength, and high temperature requirements. It is an indispensable and important material for departments such as chemical engineering, optics, and chemical laboratories.
Physical and chemical property data
Component: 99.99% silicon dioxide content Softening temperature: 1730 ℃
Usage temperature: Long term use at 1100 ℃, short term use at 1450 ℃
Expansion coefficient 100 ℃ -1000 ℃ 5.1-6.1 × 10 ℃ Specific heat (calorie/gram degree) 0-500 ℃ 0.2302 Thermal conductivity (kcal/meter hour degree) 20 ℃ 1.19 Light transmittance: Visible light transmittance above 93%
Specific gravity: 2.21 (g/cm ²) Hardness 7 (Mohs)
Compressive resistance 7000-10000 (g/cm ²) Tensile strength 500-7- (gc)
Impact 0.089 (g/cm ²) chart
quartz glass φ 100 * 40 (in mm) can withstand a pressure of 20 kilograms under correct and reasonable usage.
Instructions for use
1. Quartz glass products are valuable brittle materials, so they must be handled with care and care during processing, installation, and use.
2. Although quartz glass has extremely high thermal stability and compressive strength, large products that have undergone annealing processing have different stress distributions due to their different shapes. Therefore, the thermal stability and compressive strength are also different, and special attention should be paid when using them
